Zomagtc Automatic Bookcase Inside Paper Lining Gluing Machine For Sale

FOB Reference Price:Get Latest Price
$35,000.00 - $45,000.00 / Set | 1 Set/Sets (Min. Order)
Model Number:
ZTC-700C
Power(W):
13.5KW
Lead Time:
Quantity(Sets) 1 - 1 >1
Est. Time(days) 35 Negotiable
Report Suspicious Activity
Overview
Quick Details
Type:
Bookcase Inside Paper Lining Gluing Machine
Dimension(L*W*H):
650*220*185cm
Weight:
2500KGS
Warranty:
1 year
Condition:
New
After-sales Service Provided:
Free spare parts, Video technical support, Field installation, commissioning and training, Field maintenance and repair service, Online support
Place of Origin:
Henan
Brand Name:
Bookcase Inside Paper Lining Gluing Machine
Voltage:
380V
Certification:
Bookcase Inside Paper Lining Gluing Machine
Computerized:
Yes
Applicable Industries:
Hotels, Garment Shops, Building Material Shops, Manufacturing Plant, Machinery Repair Shops, Food & Beverage Factory, Farms, Restaurant, Home Use, Retail, Food Shop, Printing Shops, Construction works , Energy & Mining, Food & Beverage Shops, Advertising Company
Product name:
Automatic Bookcase Inside Paper Lining Gluing Machine
Model:
ZTC-700C
Maximum size:
450*700mm
Minimum size:
140*190mm
Board thickness:
1.0-3.0mm
Paper weight:
105-210g
Maximum speed:
20-30Pieces/min
Power supply:
13.5KW
weight:
2500KGS
Dimension:
650*220*185cm
Supply Ability
Supply Ability:
300 Set/Sets per Month whatsapp is +86 185 3946 6426
Packaging & Delivery
Packaging Details
Zomagtc Automatic Bookcase Inside Paper Lining Gluing Machine For Sale
Port
any port in CHina
Lead Time :
Quantity(Sets) 1 - 1 >1
Est. Time(days) 35 To be negotiated

Zomagtc Automatic Bookcase Inside Paper Lining Gluing Machine For Sale

Product Description

Whatsapp:+86 185 3946 6426   Wechat: missrayzm0504   Skype: missrayzm

Zomagtc Automatic Bookcase Inside Paper Lining Gluing Machine For Sale


Zomagtc Automatic Bookcase Inside Paper Lining Gluing Machine For Sale

ModelZTC-700CZTC-900CZTC-1000CZTC-1350A
Maximum size450×700mm450×900mm600×1000mm600×1350mm
Minimum size140×190mm140×190mm140×190mm140×190mm
Board thickness1.0-3.0mm1.0-3.0mm1.0-3.0mm1.0-3.0mm
Paper weight105-210g105-210g105-210g105-210g
Maximum speed20-30Pieces/min20-30Pieces/min15-25Pieces/min10-25Pieces/min
Power supply13.5KW14KW14.5KW15KW
Machine weight2500kg2700kg3500kg4000kg
Dimension (LxWxH)650×220×185cm750×220×185cm780×260×150cm850×260×185cm
Positioning accuracy±0.5mm±0.5mm±0.5mm±0.5mm

Fully Automatic Large Case Making And Inner Laminating Machine For Sale

Main Features:
The double sheets detect system with our own patent and provide the effective solution of double or more sheets feeding problem.
The photoelectric detecting and servo correcting unit help the board laminating on the inner paper quickly and accurately.
Multi circulation board feeding unit enhances the board feeding speed greatly.
A special cam mechanism makes the machine performance more stable and reliable and low fault.
The operating system with touch-screen can display the machine fault and hint directly so that operation is convenient and troubleshooting is fast.
Adopt up suction feeder is an effective solution to the problem of surface scratches
scii-font-family:Calibri;mso-hansi-font-family:Calibri;mso-bidi-font-family:'Times New Roman';font-size:10.5000pt;mso-font-kerning:1.0000pt;" >Imported glue pumping system
Main Configurations:
Imported optical scale
linear slideway,
linear motion units
Panasonic PLC,
German optical sensor components
Imported servo drive system
Panasonic servo control system
Imported glue pumping system
ZTC-700/900C Automatic Inner Laminating Machine uses servo drive, optical scale positioning, servo correction and new technology as well. This machine can finish automatically the inner paper feeding, gluing, cardboard feeding, positioning and flattening processes with high accuracy, fast speed and high quality product and provides inner laminating products solution at first time in the printing and packaging industry.

cover allcovers



Company Information

Zhengzhou Zomagtc Company Ltd. have been designing, developing, manufacturing

 and marketing Machinery for more than 10 years. Firstly we mainly sever china mainland

customers. In order to adapt to world market development, now we do the exporting business

directly. After these years of development, we have high quality professional teams, skillful

talents, strong technical force, strong and independent research and development capabilities,

advanced production equipment and a perfect after-sales service system.
